Gate Specifications Comparison
Product | Gate Diameter | Post Diameter | Opening Width | Gate height | Hinge Type | Finishing |
| SCGATE - Self Closing Swing Gate | B34 - 34mm OD / 25NB Pipe | C42 - 42mm OD / 32NB Pipe OR D48 - 48mm OD / 40NB Pipe | 1000mm | 550mm | Steel (Enclosed Spring) | Powder-coated Safety Yellow |
| TC461 - Self Closing Single Railing Gate | C42 - 42mm OD / 32NB Pipe | D48 - 48mm OD / 40NB Pipe | 900mm / 1200mm | 500mm | Plastic (Enclosed Spring) | Galvanised Steel (Optional Powder-Coating) |
| TC462 - Self Closing Double Railing Gate | C42 - 42mm OD / 32NB Pipe | D48 - 48mm OD / 40NB Pipe | 1700mm / 1800mm | 500mm | Plastic (Enclosed Spring) | Galvanised Steel (Optional Powder-Coating) |
| Mezzanine Pallet Up & Over Gate | B34 - 34mm OD / 25NB Pipe OR C42 - 42mm OD/32NB Pipe | N/A | B34: 1700mm / 2000mm C42: 2000mm / 2500mm / 2900mm | 2100mm (inside) 2250 (outside) | Galvanised Steel (Tube Fitting) | Galvanised Steel (Optional Powder-Coating) |
| Scaffold Swing Gate | N/A | D48 - 48mm OD / 40NB Pipe | 760mm | 960mm | Steel Couplers (Exposed Spring) | Powder-coated Red |
| End Bay for Swing Gate Kwikstage | N/A | D48 - 48mm OD / 40NB Pipe | 470mm | 920mm | Steel Couplers (Exposed Spring) | Powder-coated Red |
| Scaffold Swing Gate Adjustable Width | N/A | D48 - 48mm OD / 40NB Pipe | 1000mm > 1300mm | 500mm | Steel Couplers (Exposed Spring) | Galvanised Steel |
Product | SCGATE - Self Closing Swing Gate | TC461 - Self Closing Single Railing Gate | TC462 - Self Closing Double Railing Gate | Mezzanine Pallet Up & Over Gate |
Gate Diameter | B34 - 34mm OD / 25NB Pipe | C42 - 42mm OD / 32NB Pipe | C42 - 42mm OD / 32NB Pipe | B34 - 34mm OD / 25NB Pipe OR C42 - 42mm OD/32NB Pipe |
Post Diameter | C42 - 42mm OD / 32NB Pipe OR D48 - 48mm OD / 40NB Pipe | D48 - 48mm OD / 40NB Pipe | D48 - 48mm OD / 40NB Pipe | N/A |
Opening Width | 1000mm | 900mm / 1200mm | 1700mm / 1800mm | B34: 1700mm / 2000mm C42: 2000mm / 2500mm / 2900mm |
Gate height | 550mm | 500mm | 500mm | 2100mm (inside) 2250 (outside) |
Hinge Type | Steel (Enclosed Spring) | Plastic (Enclosed Spring) | Plastic (Enclosed Spring) | Galvanised Steel (Tube Fitting) |
Finishing | Powder-coated Safety Yellow | Galvanised Steel (Optional Powder-Coating) | Galvanised Steel (Optional Powder-Coating) | Galvanised Steel (Optional Powder-Coating) |
Product | Scaffold Swing Gate | End Bay for Swing Gate Kwikstage | Scaffold Swing Gate Adjustable Width | |
Gate Diameter | N/A | N/A | N/A | |
Post Diameter | D48 - 48mm OD / 40NB Pipe | D48 - 48mm OD / 40NB Pipe | D48 - 48mm OD / 40NB Pipe | |
Opening Width | 760mm | 470mm | 1000mm > 1300mm | |
Gate height | 960mm | 920mm | 500mm | |
Hinge Type | Steel Couplers (Exposed Spring) | Steel Couplers (Exposed Spring) | Steel Couplers (Exposed Spring) | |
Finishing | Powder-coated Red | Powder-coated Red | Galvanised Steel | |
